Features
- Protect bare fiber in any situation against mechanical damage during handling and installation.
- Bare fiber can be easily installed more than 5 meters.
- High resistance to creep, impact, and flex fatigue; flexibility at low temperature; and good retention of properties at elevated temperatures.
-
Specifications
Material Properties
.png)
§ 本產品材質具有抗酸鹼、耐高溫、抗油氣之特性。
§ 符合歐盟REACH法規及RoHS認證。
| Operating Temperature | -40°C ~ + 85°C | ||
| Storage Temperature | -20°C ~ + 60°C | ||
| Tubing Shrinkage | 1.0 | ||
| Material | Property | Value | Unit |
| Self-Extinguishing Engineering Thermoplastic Elastomer |
Tensile Modulus | 555 | MPa |
| Tensile Strength at Yield | 27.5 | MPa | |
| Elongation at Yield | 16 | % | |
| Flexural Modulus | 660 | MPa | |
| Flexural Strength | 24.5 | MPa | |
| Vicat Softening Point | 197 | oC | |
| Water Absorption | 0.2 | % | |
| Shrinkage | 1.5% | ||
| Flammability, UL94 | V-0 | ||
| Operating Temperature | -40 ~ +90 °C | ||
§ 本產品材質具有抗酸鹼、耐高溫、抗油氣之特性。
§ 符合歐盟REACH法規及RoHS認證。
